🌀 Usongshine 5010 50mm x 10mm DC Brushless Cooling Fan (5V / 12V / 24V) – DFM5010S | AuscomTech

The Usongshine 5010 50mm × 10mm Brushless Cooling Fan is a high-performance, ultra-quiet cooling solution designed for 3D printers, electronics enclosures, PC mods, robotics projects, and general-purpose cooling.
Built for longevity and stable airflow, the DFM5010S model delivers reliable cooling performance in 5V, 12V, and 24V versions.

⭐ Key Features

• Ultra-Quiet Operation – ideal for noise-sensitive environments.

• Long Life Rating – engineered for 3–5 million hours of runtime.

• High Airflow Efficiency – excellent cooling in compact spaces.

• Multiple Voltage Options – available in 5V / 12V / 24V.

• Reliable Usongshine Brand – trusted in the 3D printing community.

• Standard 5010 Frame – 50×50×10 mm with 40 mm mounting spacing.

• Brushless Motor Design – reduced wear and improved reliability.

📊 Technical Specifications (DFM5010S – Sleeve Bearing)

Physical Dimensions

• Size: 50 × 50 × 10 mm

• Mounting Hole Spacing: 40 × 40 mm

• Bearing Type: Sleeve

• Weight: 20 g

• Connector: 2-pin (varies by voltage)

🔌 Voltage Variants

5V Version (DFM5010S-5V)

• Rated Voltage: 5V DC

• Operating Voltage: 4.5–5.5V

• Current: 0.20A

• Speed: 4500 RPM

• Airflow: 9.42 CFM

• Static Pressure: 2.27 mmH₂O

• Noise Level: 26.1 dBA

• Connector: XH2.54-2P

12V Version (DFM5010S-12V)

• Rated Voltage: 12V DC

• Operating Voltage: 10.8–13.2V

• Current: 0.12A

• Speed: 4500 RPM

• Airflow: 9.42 CFM

• Static Pressure: 2.27 mmH₂O

• Noise Level: 26.1 dBA

• Connector: PH2.0-2P

24V Version (DFM5010S-24V)

• Rated Voltage: 24V DC

• Operating Voltage: 21.6–26.4V

• Current: 0.08A

• Speed: 3500 RPM

• Airflow: 7.30 CFM

• Static Pressure: 1.77 mmH₂O

• Noise Level: 20.8 dBA

• Connector: XH2.54-2P

🧩 Compatible With

• Prusa, Reprap, Ender, Anycubic 3D printers

• Hotend / extruder cooling

• Controller boards (SKR, RAMPS, Creality, Duet)

• CNC machines, laser engravers

• Raspberry Pi, Arduino, ESP32 enclosures

• Network equipment cooling

• Robotics & custom electronics

🧰 Typical Applications

• Hotend cooling

• Motherboard & stepper driver cooling

• Power supply ventilation

• PC and electronics airflow

• Robotics cooling

• Enclosure ventilation

• DIY IoT & embedded hardware projects

📦 Package Includes

• 1 × Usongshine 5010 (DFM5010S) DC Brushless Cooling Fan
  (Choose 5V, 12V, or 24V)
